Reading a result
Every comparison opens the same way: counts first, then the detail. The chassis around the diff is identical for all five engines, so learning it once is enough.
The summary strip#
| Part | What it is |
|---|---|
17 changes | The total: added plus removed plus modified |
| ＋4 added | Present on both sides but new here |
| －2 removed | Gone from the after side |
| ～11 modified | Changed in place |
| Engine chips | Whatever this engine counts that the three above cannot express |
3 suppressed | Differences that existed and were hidden by an option you set |
‹ 3 / 17 › | The change stepper |
| A trailing chip | before ↔ after, so a screenshot of the strip identifies itself |
The three coloured counts come from the engine, not from the view. That distinction matters as soon as you touch a normalisation option: those options re-run the comparison rather than filtering what is on screen, so the counts always describe exactly what you are looking at.
The chips each engine adds#
The strip renders these verbatim — it knows nothing about engines, which is how each one gets its own vocabulary without a special case.
| Engine | Adds |
|---|---|
| Text | The line count of the longer side |
| JSON | The node count, and a ⚠ N type changes chip when a value changed type |
| Folders | How many files were identical, how many were paired as renames, how many were unreadable, the total size delta, and a partial scan chip when the tree hit the entry cap |
| Images | The percentage of pixels that differ, the number of changed regions, and a size mismatch chip when the dimensions differ |
| Binary | The verdict — identical or different — and the byte delta when the sizes differ |
Stepping through changes#
‹ 3 / 17 › in the strip and ⌥↑ / ⌥↓ are the same control. So is whatever the
view does to bring a change into sight.
The view registers how many changes it has and how to reveal any one of them; the store owns which
change is current. That is why the number, the keys and the scroll position cannot drift apart —
there is only one index. Before you have stepped anywhere the position reads –, and with nothing to
step through the stepper is not rendered at all.
⌥↑ and ⌥↓ only take over the keys when a comparison actually has changes; otherwise they are left to the system. Full detail in Change navigation.
The status line#
The bar along the bottom carries the facts about the comparison itself rather than about the diff:
| Side | Shows |
|---|---|
| Left, while running | The engine's label and the current stage |
| Left, when finished | Which engine ran, then how the before input was decoded — its encoding and its line endings |
| Right, while running | The percentage |
| Right, when finished | Compared in 42 ms |
Encoding and line endings live here rather than in a chip because they are facts about the files, and because they answer the question "why does line 1 differ when it looks identical?" — a byte-order mark or a CRLF/LF mismatch, usually. See Encodings.
The toolbar#
| Control | Notes |
|---|---|
| The engine chip | Names the engine that actually ran, which is the authoritative answer if it disagrees with the detection bar |
| The engine's own controls | View modes, filters, thresholds — each view portals its controls into this one toolbar rather than drawing its own |
| The search box | A find in the text diff and a filter in the JSON and folder views; disabled, not inert, for views that do not use it. See Search and filter |
| Export ▾ | Three formats, and ⌘⇧E to repeat the last one |
| ← New comparison | Clears both inputs as well as the result — "new" means new |
| A breadcrumb | Only after a folder drill-in: it returns to the parent comparison without re-running it, so a 10,000-file scan is never repeated because you opened one file |
When a comparison fails#
The failure panel is deliberately plain: what happened, in the engine's own words, and the ways out.
| Element | Behaviour |
|---|---|
| Comparison failed | Anything that went wrong, including an engine crash |
| Comparison cancelled | You pressed Cancel. Rendered in muted text, not in the failure colour |
| The message | The engine's own — a JSON parse error names the line and column; a missing file names the file |
| Back to Compare | Returns to the two inputs |
| Copy details | Puts the reason, both input names with their kinds, and the engine on the clipboard. Not offered for a cancellation, because there is nothing to report |
TwinScope crash: The comparison engine stopped unexpectedly. Try again.
before: app-v1.bin (binary)
after: app-v2.bin (binary)
engine: Binary comparisonFour lines, pasteable into an issue: the failure reason, both inputs with the kinds TwinScope decided they were, and the engine that was running. The kinds are there because a surprising kind is the cause of a surprising failure more often than the engine is.
An engine can offer a way out#
Some failures are only failures for that engine. When one knows another engine could still say something useful, it attaches that suggestion to the error and the panel renders it as the primary button.
The worked example is unparseable JSON: the structural engine cannot proceed, but the two files are still text, so the panel offers Compare as text and one click gets you a line diff of the file that would not parse — which is usually exactly what you need to find the stray comma.
Taking it with you#
Export writes a self-contained HTML report or a Markdown summary, or copies a unified patch to the clipboard. Reports carry the same counts, options and normalisation notes you are looking at, so the file explains itself to whoever opens it. See Export.
